Supported CPU Socket 775 Intel Core 2 Quad/ Core 2 Duo/ Pentium Series/ Celeron Series Processor North Bridge – Intel G41
Chipset South Bridge – Intel 82801GB
Memory supported 2 DDR2 dual-channel RAM slots, Memory up to 4GB, Supports DDR2 800/667MHz memory, 2 x DIMM Slots
BIOS AMI BIOS
I/O Interface 1 x PS/2 keyboard, 1x PS/2 mouse port, 1 x VGA Port, 4 x USB 2.0 ports, RJ45 LAN port, 1 x 3-in-1 audio jacks
Onboard interface 1 x Front panel connector, 1 x Front audio connector, 1 x COM Connector, 2 x USB 2.0 Connectors,
4 x SATA Ports, 1 x IDE slot, 1 x 4 pin CPU fan connector, 1 x 24-pin ATX power connector,
1 x 4-pin ATX 12V power connector, 1 x clear CMOS header
Integrated LAN Supports RTL8106E 10/100 Mbps Ethernet LAN
Expansion slot 1 x PCI Express x16 slot
Form factor Micro-ATX
Package contents G41-D2 Motherboard, I/O Backboard, SATA Cable, IDE Cable, Driver disc, User manual.
